    Construction Machinery Load Cell

    Rudrra Sensor is engaged in manufacturing, supplying & exporting innovative range of Construction Machinery Load Cell (RSL 60048). It is used in weighing platforms in various industries as the dynamic load measurement. The machinery load cell has been built with premium tool steel. The moment-compensated design offers minimal sensitivity to moments which are induced by off-center loading.

    Constructed with the use of most advanced technologies, it has highly demanded features that play a vital role in yielding remarkable output. With a view to meeting every requirement of clients, the futuristic machinery load cell comes in several designs. In addition, it is altered as per specific needs too.

    Owing to the enviable performance, it is used in many industries such as belt conveyor scale, bench and counting scale, batching plant, construction machineries and more.

  • Applications

    • Belt conveyor scale
    • Bench and counting scale
    • Batching plant
    • Construction machineries

  • Diagram

    Construction Machinery Load Cell - diagram

    Dimentions

    Construction Machinery Load Cell - dimensions

  • Features

    • Built with tool steel
    • Moment-compensated design
    • Highly efficient
    • Tensile strength

  • Dimenstions

    Related Load (kg.) 22.5,45,90
    Precision C3 Insulation Resistance(MΩ) ≥20000 (10VDC)
    Composition Error 0.02 Excitation Voltage (V)9~12 (DC)
    Rated Output (mv/v) 2.00±2% Compensated temp. Range (°C)-10~+40
    Non-Linearity (%FS)0.017 Use Temp. Range (°C) -35~+65 °C
    Hysteresis (%FS)0.02 Temp. Effect on Zero (%FS/10°C)0.0017
    Repeatability (%FS)0.01 Temp. Effect on Span (%FS/10°C)0.014
    Creep (%FS/30min) 0.02 Safe Overload (%FS)120
    Zero Balance (%FS)±2 Ultimate Overload (%FS)150
    Input Resistance (Ω)395±5 Defend GradeIP67
    Output Resistance (Ω) 350± 5 Cable6mm, 5.0Mtr
